| 类目Category | 描述Descriptions | |
| 型号Model | 序列No. | YL-8502 |
| 核心模块 Nucleus Module | CPU | Intel® Celeron® Processor J1900 (Quad Core 2M Cache, up to 2.42 GHz) |
| Intel® Celeron® Processor N2930 (Quad Core 2M Cache, up to 2.16GHz) | ||
| Intel® ATOM® Processor E3845 (Quad Core 2M Cache, 1.91GHz) | ||
| 芯片组Chipset | Intel®Bay Trail D/I/M SOC integrated chipset | |
| BIOS | AMI 64Mbit Flash ROM | |
| 内存RAM | Onboard DDR3L 1333MHZ 2GB/4GB /8GB | |
| 硬盘Storage |
1*mSATA slot(32G/64G/128G/256G SSD), 1*SATA bay(7+15P 500G-1T 2.5" HDD), optional | |
| 显卡Graphic | Integrated Intel®Bay Trail D/I/M SOC | |
| 网卡Network |
2*Intel® Ethernet Controller I211AT 1000M lan (Support Intel® Ethernet Controller I210 Series) | |
| 声卡Audio | Realtek ALC892 | |
| 接口I/O | 网口Lan | 2*RJ45 (Gigabit Ethernet) |
| USB | 5*USB2.0, 1*USB3.0 | |
| 显示Display | 1*VGA; 1*HDMI | |
| WIFI | 1*WiFi module with 2 antennas(Optional) | |
| 串口COM | 4*COM(RS232) | |
| 按钮Button | 1*Power Button | |
| 喇叭SPK | 1* Audio-out | |
| Mic | 1*Mic-in | |
| 扩展Expansion | 1*mini-PCIe (for WiFi and Bluetooth) | |
| 系统OS | Operating System | Windows 7/8/10, Linux |
| 机构Structure | Dissipation | high-quality profile case for quick heat dissipation |
| 外壳Housing | aluminum alloy | |
| Bracket | VESA bracket(Optional) | |
| Dimensions | 134 * 124 * 46mm / 5.28 * 4.88 * 1.81 Inch (WxDxH) | |
| Weight | 0.59KG(N.W.) | |
| 电源Power | DC In | DC 12V-IN power supply and AC power adapter |
| 温/湿度 Temperature & Humidity | Working Temp. | -40°C~ 65°C (-40°F~149°F) |
| Strorage Temp. | -40°C~ 85°C (-40°F~185°F) | |
| Working Humidity | 10% - 95% relative humidity(Non-condensing) | |
| 认证Cert. | Safety | CE, FCC, RoHS |
| 包装Packing | 清单Items |
pc, power adapter, power cord, CD driver, VESA Bracket & 2 Antennas(Optional) |
